Mini Roll Compactor (Cantilever) with cake Crusher & Granulator

Mini Roll Compactor (Cantilever) with cake Crusher & Granulator

Cantilever type Roll Compactor with cake Crusher & Two-Stage Oscillating Granulator.

This high-end model operates in a completely enclosed manner to comply with the highest standard of cGMP guidelines by optimum utilization and at minimal operating cost and wastage.

Request A Quote
Features
  • Cantilever rolls design
  • In line roll compactor with cake crusher & 2 stage granulator
  • Comply with cGMP requirements
  • WIP Provision
  • Water jacketed
  • Contact parts S.S.316 without roll
  • Machine mobility
  • PLC system
  • 21 CFR part 11 compliance. (Optional)
Technical Specifications
MODEL CPMMRCCG 100 / 25 C1
Working Capacity* 2 to 5 kg / hr*
Roll Size ∅100 * 25 W
Roll Speed 3 to 29 RPM
Feed Screw Speed (Horizontal) 60 RPM
Feed Screw Speed (Vertical) 200 RPM
Roll Force 5 Ton
Electrical Supply** 5.5 HP, 1∅, A.C.
